Tabletop 6-inch IR Furnaces

Radiant Technology Corporation (RTC)

SMD-206 Tabletop Production/Lab Solder Reflow System for Surface Mounted Devices SMD-206 Tabletop IR Furnace

The RTC SMD-206 is a general purpose tabletop conveyorized infrared furnace system with a 6-inch wide belt designed for the reflow solder attachment of Surface Mounted Devices on ceramic and glass epoxy substrates. It is also suited for many other curing, heating, and drying applications. Clean efficient infrared heat is uniform through the heating section. The unit is extremely small and compact and can be easily moved about as necessary.

 Solid state contols are employed for temperature and speed control. The SMD-206 has built-in line voltage regulation designed to keep heat output and conveyor speed constant despite fluxuations in line voltage. Perfect for solder reflow applications and other precision low temperature drying and curing applications.

Reflow solder paste for the attachment of Surface Mounted Device on ceramic or glass substratesDry solder paste prior to vapor phase solder reflow
Cure polymer thick film materialsBake photo resist on silicon wafers
Cure epoxy potting compoundsCure conformal coatings
Cure offset printed marking inksCure low temperature optical coatings
Cure nomenclature and legend inks on printed circuit boardsFuse components to pre-tinned or solder paste screen printed hybrid micro-circuits
Cure bonding epoxies or encapsulating epoxies on integrated circuitsDry thick film paste (to remove solvent fumes) on hybrid circuits prior to firing
Cure resist inks on printed circuit boardsProcess heat shrink tubing

Conveyor width: 6 inches
Conveyor speed: 0 to 60 inches per minute solid state digital speed control
Max Design Temperature: 400C (752F)
Throat height: 2" above belt (standard, verify on each unit)
Heated Length: 1 Zone (23 inches long)
Atmosphere: 300 scfh maximum, Air, Nitrogen, or Forming Gas (FG*)
Process exhaust: 300 scfh maximum, venturi assist
Cabinet ventillation:  75 cfm
Voltage: 120 Vac, 3.5 kW, 30 A

Size: 54" L x 14.25 W" x 22.25" H (length may vary depending on options)
Weight:  135 LB

BrochureSMD-206 tabletop furnace brochure pdf
ManualSMD-206 tabletop furnace manual pdf
Arrangement DrawingSDM-206 tabletop furnace installation drawing pdf


*FG - Forming Gas must be a non-flammable hydrogen/nitrogen mix (less than 5% hydrogen in nitrogen).
